Stroke 02: Workup

Stroke care begins with prevention by addressing modifiable risk factors such as inactivity, HLD, diet, HTN, obesity, DM, cigarette smoking, cardiac disease, carotid stenosis and managing sickle cell. Non-modifiable risk factors include older age, male, race, family history, genetics and low birth weight. Much of this will hopefully occur with the patient’s primary care physician prior to coming to the Emergency Department.

However once in the Emergency Department, we have several priorities when evaluating the potential stroke patient.

  1. Determine time of onset (last known well, LKW)
  2. Eliminate any contra-indications to thrombolytics
  3. Rule out any stroke mimics
YouTube Videos on Stroke Care

Introduction to Ischemic Stroke

Stroke Anatomy

Stroke Evaluation

Stroke Treatment

primary survey

Of course, start with ABC’s. Medullary injury and bleeds can lead to loss of airway.

  • take care of ABCs, glucose, temp
  • permissive HTN: sBP < 220 to promote cerebral autoregulation and blood flow, if they got tPA then at or below 185/110
  • avoid hyperthermia
  • control sugars < 200
  • keep sats at or above 94% (no supplemental O2 if ≥ 94%)

history

In addition to your normal history questions, focus on the following:

  1. Last Known Well (LKW): Ask paramedics, patient, family the last time the patient was at their baseline level of functioning. You may have to call family at home. There are two times this may not be possible: the aphasic or obtunded patient or the patient who went to bed normal and woke up with symptoms (“wake-up strokes”).
  2. Stroke risk factors: HTN, DM, AF, HLD, tobacco use, family history, CKD, sleep apnea
  3. Meds: particularly any anticoagulants and the last time they took them.
  4. Rule out stroke mimics: seizures (Todd’s paralysis or AMS can be confused as a stroke), migraines (can be hemiplegic and have brainstem aura that leads to dysarthria), Bell’s palsy (facial weakness due to CN7), HTN emergency (can have headache, AMS, blurred vision and even focal deficits), hypo and hyperglycemia, recrudescence (unmasking of old symptoms due to a stressor like infection, dehydration, fatigue), ingestions & tox (ASA, APAP, Li, dilantin, carbamazepine), degenerative neurological disorders (MS, MG, demyelinating diseases)

physical

We are very spoiled at Rush with Neurology residents who can perform the NIHSS quickly and report the score to us. In other places, you may be required to do this yourself. MDCalc has a calculator that can walk you through all the elements. If you log in, you can copy the results to your chart. It’s here if you need it as well.

NIH Stroke Scale
FeatureSymptomsScore
1A: LEVEL OF CONSCIOUSNESSAlert; keenly responsive0
Arouses to minor stimulation1
Requires repeated stimulation to arouse2
Movements to pain2
Postures or unresponsive3
1B: ASK MONTH AND AGEBoth questions right0
1 question right1
0 questions right2
Dysarthric/intubated/trauma/language barrier1
Aphasic2
1C: BLINK EYES & SQUEEZE HANDSPerforms both tasks0
Performs 1 task1
Performs 0 tasks2
2: HORIZONTAL EXTRAOCULAR MOVEMENTSNormal0
Partial gaze palsy: can be overcome1
Partial gaze palsy: corrects with oculocephalic reflex1
Forced gaze palsy: cannot be overcome2
3: VISUAL FIELDSNo visual loss0
Partial hemianopia1
Complete hemianopia2
Patient is bilaterally blind3
Bilateral hemianopia3
4: FACIAL PALSYNormal symmetry0
Minor paralysis (flat nasolabial fold, smile asymmetry)1
Partial paralysis (lower face)2
Unilateral complete paralysis (upper/lower face)3
Bilateral complete paralysis (upper/lower face)3
5A: LEFT ARM MOTOR DRIFTNo drift for 10 seconds0
Drift, but doesn’t hit bed1
Drift, hits bed2
Some effort against gravity2
No effort against gravity3
No movement4
Amputation/joint fusion0
5B: RIGHT ARM MOTOR DRIFTNo drift for 10 seconds0
Drift, but doesn’t hit bed1
Drift, hits bed2
Some effort against gravity2
No effort against gravity3
No movement4
Amputation/joint fusion0
6A: LEFT LEG MOTOR DRIFTNo drift for 5 seconds0
Drift, but doesn’t hit bed1
Drift, hits bed2
Some effort against gravity2
No effort against gravity3
No movement4
Amputation/joint fusion0
6B: RIGHT LEG MOTOR DRIFTNo drift for 5 seconds0
Drift, but doesn’t hit bed1
Drift, hits bed2
Some effort against gravity2
No effort against gravity3
No movement4
Amputation/joint fusion0
7: LIMB ATAXIANo ataxia0
Ataxia in 1 Limb1
Ataxia in 2 Limbs2
Does not understand0
Paralyzed0
Amputation/joint fusion0
8: SENSATIONNormal; no sensory loss0
Mild-moderate loss: less sharp/more dull1
Mild-moderate loss: can sense being touched1
Complete loss: cannot sense being touched at all2
No response and quadriplegic2
Coma/unresponsive2
9: LANGUAGE/APHASIANormal; no aphasia0
Mild-moderate aphasia: some obvious changes, without significant limitation1
Severe aphasia: fragmentary expression, inference needed, cannot identify materials2
Mute/global aphasia: no usable speech/auditory comprehension3
Coma/unresponsive3
10: DYSARTHRIANormal0
Mild-moderate dysarthria: slurring but can be understood1
Severe dysarthria: unintelligible slurring or out of proportion to dysphasia2
Mute/anarthric2
Intubated/unable to test0
11: EXTINCTION/INATTENTIONNo abnormality0
Visual/tactile/auditory/spatial/personal inattention1
Extinction to bilateral simultaneous stimulation1
Profound hemi-inattention (ex: does not recognize own hand)2
Extinction to >1 modality2
NIHSS, 11 items with a score between 0 and 42. MINOR STROKE < 5. SEVERE STROKE > 20.

do the symptoms match a particular vascular distribution?

The stroke should make sense with a particular artery being blocked. Stroke mimics can often cross distributions. The commonly blocked large vessel occlusions include the basilar artery, ICA, MCA and vertebral.

anterior circulation

  • Anterior Cerebral Artery (ACA)
    • frontal lobe: apathy, disinhibition, abulia (lack of will or initiative)
    • olfactory cortex: trouble with smell
    • leg motor cortex: contralateral motor/sensory loss
  • Middle Cerebral Artery (MCA)
    • speech and language areas: aphasia
    • motor and sensory cortices: motor and sensation of contralateral arm and face
    • basal ganglia: motor control and coordination
    • internal capsule/corona radiata: motor and sensory pathways
    • →, neglect, forced eye deviation, contralateral homonymous hemianopsia,
  • Posterior Cerebral Artery (PCA)
    • occipital lobe: visual field loss
    • midbrain: movements of the eye
    • thalamus: contralateral loss of pain and temperature
    • corpus callosum
  • Posterior communicating Artery = common site for aneurysm = thalamus, hypothalamus, optic chiasm → headache, vision changes
  • Anterior Communicating Artery = connects bilateral anterior circulations and another common site for aneurysms → visual symptoms due to proximity to optic nerve

posterior circulation

  • Posterior Inferior Cerebellar Artery (PICA) = cerebellum, medulla, choroid plexus of 4th ventricle → ipsilateral limb ataxia, ↓pain and temp sensation contralaterally
  • Anterior Inferior Cerebellar Artery (AICA) = cerebellum & pons → ipsi deafness, facial motor/sensory loss & limb ataxia, ↓pain and temp sensation contralaterally
  • Basilar Artery = cerebellum, midbrain, pons, medial, thalamus, hypothalamus, inferior occipital and temporal lobes → ↓LOC, facial paresis, oculomotor difficulties, ataxia, quadraparesis
vascular distributions in much more details than you probably ever wanted to know
ArteryStructure SuppliedAssociated FunctionAssociated Condition
Anterior Cerebral Artery (ACA)Medial Frontal LobeExecutive functions, decision-making, personalityPersonality changes, impaired executive function, abulia
Medial Primary Motor CortexMotor control for the lower limbsContralateral hemiparesis (lower limbs)
Medial Parietal LobeSensory processing (lower limb)Contralateral sensory loss (lower limbs)
Anterior Corpus CallosumInterhemispheric communicationSplit-brain syndrome
Middle Cerebral Artery (MCA)Lateral Frontal LobeMotor control (face and upper limbs), cognitionContralateral hemiparesis (face, upper limbs), Broca’s aphasia
Lateral Temporal LobeAuditory processing, language comprehensionWernicke’s aphasia
Lateral Parietal LobeSensory processing (face, upper limbs), spatial awarenessContralateral sensory loss (face, upper limbs)
Right Inferior Parietal LobuleSpatial awareness, visual attentionHemi-neglect (left side)
Basal GangliaMotor control, coordinationMovement disorders (e.g., Parkinson’s, Huntington’s)
Posterior Cerebral Artery (PCA)Occipital LobeVision, visual processingContralateral homonymous hemianopia, cortical blindness
Inferior Temporal LobeMemory, recognition (faces, objects)Anomia, prosopagnosia
ThalamusSensory relay, pain perception, consciousnessThalamic pain syndrome, sensory loss
Posterior Corpus CallosumInterhemispheric communicationVisual and sensory deficits
Anterior Communicating Artery (AComA)Optic ChiasmVisual field processing, visual input coordinationBitemporal hemianopia
HypothalamusAutonomic functions, hormone regulationEndocrine dysfunctions, sleep disturbances
Posterior Communicating Artery (PComA)Optic TractVisual signal transmission, visual reflexesContralateral homonymous hemianopia
ThalamusSensory integration, motor relay, consciousnessThalamic pain syndrome, sensory loss
HypothalamusHomeostasis, autonomic control, hormone regulationEndocrine dysfunctions, autonomic issues
Internal Carotid Artery (ICA)ACA and MCA OriginMajor supply to frontal, parietal, temporal lobesIschemic stroke (ACA, MCA territories)
Basilar ArteryBrainstemAutonomic functions (breathing, heart rate), consciousnessLocked-in syndrome, respiratory failure
CerebellumBalance, motor coordinationAtaxia, coordination deficits
Vertebral ArteryMedullaAutonomic functions, respiration, heart rateRespiratory arrest, cardiovascular dysfunction
Inferior CerebellumBalance, fine motor coordinationAtaxia, vertigo
Anterior Choroidal ArteryOptic Tract, Lateral Geniculate NucleusVisual signal processingContralateral homonymous hemianopia
Posterior Limb of Internal CapsuleMotor and sensory pathwaysHemiparesis, hemisensory loss
HippocampusMemory formation and retrievalMemory deficits
Posterior Inferior Cerebellar Artery (PICA)Inferior CerebellumBalance, coordinationAtaxia, vertigo
Lateral MedullaAutonomic functions, reflexesWallenberg syndrome (lateral medullary syndrome)
Anterior Inferior Cerebellar Artery (AICA)Inferior Cerebellum, Inner EarBalance, hearingAtaxia, hearing loss, vertigo
Superior Cerebellar Artery (SCA)Superior CerebellumBalance, coordinationAtaxia, dizziness
Lenticulostriate ArteriesBasal Ganglia, Internal CapsuleMotor control, coordinationLacunar infarcts, movement disorders
Ophthalmic ArteryRetinaVisionVision loss (monocular blindness)
Pontine ArteriesPonsMotor control, autonomic functionsPontine stroke, locked-in syndrome
Vascular Distributions in stroke.
